CAUTION: Accessible parts may be hot when the grill is in use. Young
children should be kept away.
CAUTION: This appliance is for cooking purposes only. It must not be
used for other purposes, for example room heating. When fitting a gas
hob above a drawer or a standard housing unit, suitable precautions
must be taken to prevent contact with the hotplate surface as it can
become very hot during operation.
The recommended method is to fix a wooden panel within the
cabinet at a distance of 15mm below the underside of the hob (Fig. 6).
This panel must have adequate ventilation to the rear.
NOTE: The panel underneath the hob must be easily removable to
allow for any servicing requirements. When installed, the hob depth is
35mm plus 20mm terminal for MXG030SS and 40mm for
MXG060SS/MXG070SS from the surface of the worktop.
Installing and fixing the hob
Before inserting the hob into the work surface, please follow the
below instructions:
1. Remove the pan stands and burner caps before turning the hob
upside down, taking care not to damage the ignition plugs and
thermocouples.
2. Place the seal “S” around the bottom edge of the hob as shown in
the illustration below.
