►►►1. SAFETY INFORMATION
(PIC. 1)
IMPORTANT: This heater is not suitable for use by persons (includ-
ing children) with reduced physical, sensory or mental capacities or
with lack of experience or knowledge unless supervised by a person
responsible for their safety. Children must be supervised to make
sure they do not play with the heater.
IMPORTANT: All cleaning, maintenance and repair operations that
involve access to dangerous parts (such as replacing a damaged
power cable) must be performed by the manufacturer, by their
support centre, or by a person with a similar qualication, in order
to prevent any risk, even if disconnection from the electrical mains
is required.
IMPORTANT: Comply with all local legislation and current regula-
tions when using the heater. Do not leave the heater running unat-
tended or near children or animals.
CAUTION: Some parts of this heater can become very hot and cause
burns.
►1.1. Heaters used near tarpaulins, curtains or other similar covering
materials must be a safe distance from them. It is advised to use re-
proof covering material.
►1.2. The heater must be used in a dry environment. Keep the heater
a safe distance from humidity, water and atmospheric agents to pre-
vent serious damage to the heater. Do not use the heater outdoors.
►1.3. Maintain a safe distance from the hot parts of the heater and
ammable or heat-sensitive materials (including the power cable).
If the power cable is damaged, it must be replaced by the service
centre to prevent any risk. Maintain a distance of at least two metres
from all sides of the heater.
►1.4. To avoid burns, when the heater is hot, connected to the power
mains or during operation, it must never be touched, handled or ser-
viced. Do not place your hands in front of the heater while it is in
operation.
►1.5. For proper use, install the heater on the wall with suitable wall
plugs, on a stable, vertical wall in order to avoid falls. The wall used
for installation must be suitable to support the weight of the heat-
er. The installation must be carried out to professional standard, in
compliance with current standards, according to the instructions in
this manual. DO NOT USE THE HEATER WHILE PLACED ON THE
GROUND.
►1.6. Keep animals, children and vulnerable persons at a safe dis-
tance from the heater in operation.
►1.7. Power on the heater only with a current which has the voltage
and frequency values specied on the heater's identication plate.
The electrical connection must be carried out correctly according to
current standards. Do not use the heater electrically connected to a
power strip.
►1.8. Only connect the heater to suitable power supply networks,
suitably equipped with earth leakage circuit breakers and adequate
earthing, which allow the device to function properly.
►1.9. Disconnect the heater from the mains when not in use for a long-
er period of time.
►1.10. Always disconnect the heater from the mains if temporarily left
in unsafe conditions and in any case make sure it cannot be used.
►1.11. Do not obstruct, even partially, the air inlet (rear side) or the
air outlet (front side) of the heater, as this could cause burns, re,
electric shock, etc. to persons and property.
►1.12. Avoid ducting the air.
►1.13. Do not cover the heater while it is in operation, it may overheat.
►1.14. When switching o, avoid disconnecting the heater from the
power supply before the fan has stopped completely, in order to
avoid serious damage.
►1.15. The heater requires regular maintenance and cleaning. A dirty
or unmaintained heater is a potential re hazard.
►1.16. For any maintenance or repairs, please contact the service cen-
tre (risk of electric shock and serious injury).
►1.17. In case of malfunction, do not use the heater. Contact the ser-
vice centre immediately.
►►►2. DESCRIPTION
(PIC. 2)
This series of warm air heaters is particularly suited to heating areas, such
as warehouses, shops, restaurants and homes. These heaters comply with
the current European directive.
The fan draws in ambient air from the rear side, directing it through a series
of electrical resistances that increase its temperature. The fan then releases
the heated air back into the room through the grille at the front.
The heater is made of metal and has a double wall to increase performance
and limit the temperature on external surfaces.
In order to use the heater, the battery-operated wireless remote control (AC-
CESSORY) must be purchased.
DETAILS:
A. Wall support.
B. Adjusting screw.
C. Fastening screw.
D. Heater.
E. Main “0/OFF” - “I/ON” power supply switch.
F. “RESET“ button.
G. Power supply cable.
H. Led (active mode: ventilation, minimum power, maximum power).
►►►3. UNPACKING
WARNING: The packaging material is not a toy. Keep the plastic bag
out of the reach of children; danger of suocation!
►3.1. Remove all packaging materials used to pack and ship the heater.
Dispose of them in compliance with current regulations.
►3.2. Extract all articles from the packaging.
►3.3. Check for any damage incurred during transport. If the heater appears
damaged, immediately inform the dealer from whom it was purchased.
►►►4. ASSEMBLY AND INSTALLATION
(PIC.3)
IMPORTANT: The heater must be installed according to law, using
components in compliance with local and/or national regulations.
The manufacturer declines any liability for damage/injuries to the
heater and/or persons deriving from incorrect installation.
IMPORTANT: For the assembly and installation of the heater, care-
fully follow the instructions below.
IMPORTANT: These heaters are designed for wall installation. No
other type of installation is permitted.
Do not use the heater while placed on the ground.
IMPORTANT: The heater stand must be xed rmly to a wall suitable
for supporting the weight of the product, using the dowels provided
(the stand must be xed at four points). Improper fastening may
cause vibrations or damage the heater.
The mechanical components, complete with the relevant mounting bolts,
are located inside the packaging of the heater and must always be installed
before commissioning.
►►►5. CONNECTION TO THE POWER SUPPLY NETWORK
(PIC. 4)
IMPORTANT: The installation, adjustment and use of the heater
must comply with the applicable standards and laws for this type
of product.
Before starting up the heater and thus before connecting it to the mains,
check that the mains characteristics correspond to those on the rating plate.
The heater's power supply network must be earthed and equipped with a
safety device in accordance with the law.
The heater must be permanently supplied from the mains.
Do not electrically connect the heater to a power strip.
IMPORTANT: READ AND UNDERSTAND THIS OPERATIONAL MANUAL PRIOR TO ASSEMBLING, STARTING
UP OR CONDUCTING MAINTENANCE ON THIS HEATER. INCORRECT USE OF THE HEATER CAN CAUSE
BURNS, FIRE, ELECTRIC SHOCK, INJURY OR DAMAGE TO PERSONS OR PROPERTY. KEEP THIS MANUAL
FOR FURTHER REFERENCE.
