 If the cable is damaged or to be replaced, the operation must be carried out the by after-sale agent

with dedicated tools to avoid any accidents.

 If the appliance is being connected directly to the mains an omnipolar circuit-breaker must be

installed with a minimum opening of 3mm between contacts.

 The installer must ensure that the correct electrical connection has been made and that it is

compliant with safety regulations.

 The cable must not be bent or compressed.

 The cable must be checked regularly and replaced by authorised technicians.

If the total number of heating unit of the appliance you choose is not less than 4, the appliance can

be connected directly to the mains by single-phase electric connection, as shown below.

Yellow / Green

Black

Brown

Blue

380-415V~

220-240V~

1

2

3

4

5

N1

L1

L2

1

2

3

4

5

N2

Yellow / Green

Black

Brown

Blue

220-240V~

1

2

3

4

5

L1

L2

N1

N2

1

2

3

4

5

220-240V~

25A~

EN-25
