Handleiding

WARNING: Ensuring

Adequate Ventilation

Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not

blocked.

In

order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable

electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum

distance of 50mm from the bottom of the hob. Follow the requirements

below

.

There are ventilation holes around outside of the hob. YOU MUST ensure these holes

are not blocked by the worktop when you put the hob into position.

 Be aware that the glue that join the plastic or wooden material to the furniture,

has to resist to temperature not below 150℃, to avoid the unstuck of the

paneling.

 The rear wall, adjacent and surrounding surfaces must therefore be able to

withstand an temperature of 90℃.

A(mm) B(mm) C(mm) D E

760 50 mini 20 mini Air intake Air exit 5mm

A

B

E

C

D

EN-22

Min. 5 cm

Max. 5 mm Max. 5 mm
