24
8/22 Rev. R 132617 ©2022 Refrigerated Solutions Group. All rights reserved.
WALK-IN INSTALLATION
As each wall panel or corner panel is constructed and locked in an
adjoining panel along the vertical joint, engage the section latches to
the floor panels by turning the hex locking wrench ONLY ABOUT 1/4
TURN CLOCKWISE.
Make certain that the wall or corner panel is perfectly aligned with the
floor panel or foamed sealer before engaging the section latches.
Continue constructing panels
according to the part numbers shown
on the floor plan, and follow, explicitly,
the technique described for panel
alignment.
CEILING PANELS will be constructed
at specific intervals to facilitate the
installation. The intermittent ceiling
panel construction is scheduled to
allow the ceiling panels to serve as
supporting ties between opposite
walls as the installation progresses.
CAUTION! DO NOT SLIDE CEILING PANELS
INTO POSITION! To avoid gasket damage,
elevate the ceiling section clear of the wall
section while bringing it into position.
When adjoining ceiling panels are in position,
adjust the exterior edges so that they are
perfectly flush with one another and with the wall
panels directly below them. Lock the ceiling
panels securely to each other. DO NOT LOCK
ceiling panels to wall panels at this time.
NOTE: If local conditions, such as existing
building walls, make it difficult to align ceiling
panels with each other from the exterior, locate
a step ladder near the interior walls to visually
inspect the alignment and adjust as necessary.
