System setup 21
System setup
Warning! Read “Safety information” on page 4 and “Precautions to avoid damage” on page 7 before
applying power to the VC-Strip.
Setting up for P3 display
A Martin P3™ system allows video to be displayed on an installation that consists of or includes VC-Strip
devices. When a P3 controller is connected to the data link and the installation is powered on, you can set
up all the devices on the link from the P3 controller. See the P3 controller user manual for details.
Setting up for DMX control
A DMX system gives 0 - 100% variable intensity control. Varying the intensity of red, blue and green LEDs in
RGB products provides RGB color mixing. Setting red, blue and green to 100% intensity gives white, with
the option of adjusting color temperature using the red and blue LEDs.
You can set up and control a VC-Strip installation over the data link using an RDM-compatible DMX
controller.
DMX control channels
DMX controllers send control data to devices over DMX control channels in DMX universes. One DMX
universe has 512 channels available.
One DMX channel is required for each control parameter of each element in the installation. An element can
consist of an individual pixel, a VC-Strip module, or a group of modules, depending on how you set up the
VC-Strips. A control parameter can consist of red intensity, for example. So, red intensity control of one
element in an installation uses one channel. RGB control of a VC-Strip installation requires three channels
per element.
• If you set a VC-Strip to individual pixel control, you can control each LED on that VC-Strip as an individual
pixel using its own DMX channels – three channels per pixel.
• If you set a VC-Strip to module control, you can control all the LEDs on that VC-Strip as a group using the
same three DMX channels. Individual control of the pixels on that VC-Strip module is impossible.
• If you set multiple VC-Strips to module control and also set up those VC-Strips to use the same DMX
channels, you can control all the VC-Strips as a group using the same three DMX channels. Individual
control of the pixels or modules in the group is impossible.
Type of VC-Strip module
DMX channels per module,
module control
DMX channels per module,
individual pixel control
VC-Strip 32x1 15 RGB 3 96
VC-Strip 16x1 15 RGB 3 48
VC-Strip 16x1 25 RGB 3 48
VC-Strip 8x1 25 RGB 3 24
VC-Strip 16x1 30 RGB 3 48
VC-Strip 8x1 30 RGB 3 24
VC-Strip 8x1 60 RGB 3 24
VC-Strip 4x1 60 RGB 3 12
Table 5: Number of DMX channels required per VC-Strip module
