Je bekijkt pagina 5 van 32
Safety Information 5
- maximum cable lengths, and
- maximum number of devices that can be connected.
• Use only the cables specified by Martin for the devices concerned to interconnect them. If the specified
cables are not long enough for an intended cable run, consult Martin for assistance in finding or creating a
safe alternative cable
• Do not allow the total length of the cables used in a linked chain of VC-Grid modules to exceed 50 m
(164 ft.) from the 48 VDC power source (Martin P3 PowerPort 1500™, Martin IP66 PSU 240W™ or other
external PSU) to the last VC-Grid at the end of the chain.
• Do not exceed the maximum safe limits given in the tables below. The figures allow for cable in a chain
with a total hybrid cable length of 50 m (164 ft.).
- If you supply VC-Grid modules with DC power from an output on a Martin P3 PowerPort 1500, do not
connect more than one linked chain of VC-Grids to one DC power output, and respect the limits given in
Table 1 below:
- If you supply VC-Grid modules with DC power from a Martin IP66 PSU 240W, do not connect more
than one linked chain of VC-Grids to the DC power output, and respect the limits given in Table 2 below.
Type of VC-Grid module in
chain
Maximum permitted
number of modules in one
chain
VC-Grid 16x16 15 4
VC-Grid 8x8 25 12
VC-Grid 8x8 30 12
VC-Grid 8x8 60 12
VC-Grid 4x4 60 45
Table 1: Maximum number of VC-Grid modules per P3 PowerPort 1500 output
Type of VC-Grid module in
chain
Maximum permitted
number of modules in one
chain
VC-Grid 16x16 15 4
VC-Grid 8x8 25 8
VC-Grid 8x8 30 8
VC-Grid 8x8 60 8
VC-Grid 4x4 60 30
Table 2: Maximum number of VC-Grid modules per Martin IP66 PSU 240W
