8 VC-Grid Safety and Installation Guide
• Excessive dirt buildup causes overheating and a risk of short-circuits and may damage the product.
Damage caused by inadequate cleaning is not covered by the product warranty.
Operating temperature precautions
• Exposing the VC-Grid to direct sunlight or operating it in an ambient temperature that exceeds the
specified maximum may reduce the lifetime of the product. Monitor the VC-Grid’s temperature by calling
up temperature readouts on the P3 System Controller. If any of the product temperature readouts exceed
the temperatures given in Table 4, provide fan assistance to give active cooling to the installation.
• Note that, if the temperature of a VC-Grid module rises to 10° C above the level given in Table 4, a
thermal safety cutout shuts down the module. The module will not function normally again until the
temperature has fallen to a safe level.
Electrostatic discharge precautions
VC-Grid components are sensitive to ESD (electrostatic discharge) and can be damaged if you do not take
the following precautions:
• Attach an ESD wrist strap to your wrist and connect its ground (earth) lead to a known ground (earth)
before handling the VC-Grid.
• Hold the VC-Grid by its edges only. Do not touch any part of a VC-Grid module apart from the connectors
and the control button. Do not touch connector pins.
• Place the VC-Grid on grounded (earthed) surfaces only.
• Store the VC-Grid only in its ESD shielding bag and do not remove it until you are ready to install it. Place
it in an ESD shielding bag immediately if you remove it from an installation.
• Protect the VC-Grid from ESD in the installation location. Differences in electrical potential between the
VC-Grid and any object it comes into contact with may cause damage that is not covered by the product
warranty.
VC-Grid module Fan assistance required from:
VC-Grid 15 76° C
VC-Grid 25 75° C
VC-Grid 30 69° C
VC-Grid 60 4x4 69° C
VC-Grid 60 8x8 68° C
Table 4: Maximum temperature levels before fan assistance is required
