38 Exterior PixLine™ User Manual
Approvals
EU safety. . . . . . . . . . . . . . . . . . . . . .EN 60950-1, EN 60950-22, EN 62471
EU EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN 55024, EN 55032
US safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . UL 60950-1, UL 60950-22
US EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CFR Title 47 Part 15 Class A
Canadian safety . . . . . . . . . . . . . . .CSA C22.2 No. 60950-1, No. 60950-22
Canadian EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ICES-003 Class A
Australia/NZ (pending) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCM
Accessories
Magnetic Test Tool, set of 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91610139
Mounting profiles
Exterior PixLine Mounting Profile, 320 mm, Aluminum, for PixLine 10 . . . . . . . . . . . . . . . . . P/N 91611620
Exterior PixLine Mounting Profile, 1280 mm, Aluminum, for PixLine 10 . . . . . . . . . . . . . . . . P/N 91611610
Exterior PixLine Mounting Profile, 310 mm, Aluminum, for PixLine 20/40. . . . . . . . . . . . . . . P/N 91611700
Exterior PixLine Mounting Profile, 1270 mm, Aluminum, for PixLine 20/40. . . . . . . . . . . . . . P/N 91611710
Exterior PixLine Mounting Profile Locks, set of 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91611725
Cables
Power + Data Input Cable, 4-pin male XLR (for P3 PowerPort)
to female BBD, 0.25 m (9.8 in.). . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91616046
Power + Data Input Cable, 5-pin male XLR (for DMX) + wire tails (for PSU)
to female BBD, 0.25 m (9.8 in.). . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91616048
Power + Data Input Cable, 5-pin male XLR (for DMX) + 4-pin male XLR (for
P3 PowerPort) to female BBD, 0.25m (9.8 in.) . . . . . . . . . . . . . . P/N 91616049
Power + Data Input Cable, 5-pin male XLR (for DMX) + male Tripix Power IP66 or
Martin® IP66 PSU 240W to female BBD, 0.25 m (9.8 in.) . . . . . P/N 91616050
Power + Data Extension Cable, Installation Type, CMX, BBD to BBD 1 m (3.3 ft.) . . . . . . . . P/N 91616055
Power + Data Extension Cable, Installation Type, CMX, BBD to BBD, 2.5 m (8.2 ft.) . . . . . . P/N 91616056
Power + Data Extension Cable, Installation Type, CMX, BBD to BBD, 5 m (16.4 ft.). . . . . . . P/N 91616057
Power + Data Extension Cable, Installation Type, CMX, BBD to BBD, 10 m (32.8 ft.). . . . . . P/N 91616058
Power + Data Extension Cable, Installation Type, CMX, BBD to BBD, 25 m (82.1 ft.). . . . . . P/N 91616059
Power + Data Extension Cable, Installation Type, CMX,
100 m (328 ft.) bulk without connectors . . . . . . . . . . . . . . . . . . . P/N 91616060
Power + Data Output Cable, male BBD
to 4-pin female XLR, 0.25m (9.8 in.). . . . . . . . . . . . . . . . . . . . . . P/N 91616047
DMX Lead-out Cable, male BBD to 5-pin female XLR, 0.25 m (9.8 in.) . . . . . . . . . . . . . . . . P/N 91616051
Connectors
Power + Data Cable Connector, BBD, Male. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91611750
Power + Data Cable Connector, BBD, Female . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 91611751
Blanking Caps for sealing unused female BBD connectors, set of 10 . . . . . . . . . . . . . . . . . . P/N 91616052
Related Items
Martin® P3-PC System Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721030
Martin® P3-050 System Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721090
Martin® P3-150 System Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721015
Martin® P3-300 System Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721060
Martin® P3 PowerPort 1500 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721040
Martin® P3 PowerPort 1000 IP, Installation model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P/N 90721080
Martin® IP66 PSU 240W external power supply unit
(identical to Martin® Tripix Power IP66) . . . . . . . . . . . . . . . . . . . P/N 90760330
