DMX protocols 33
Segment Mode
Channel DMX Value Function
1
0 - 65535
Dimmer fade (MSB)
8-bit coarse control, closed 0% → open 100%
2
Dimmer fade (LSB)
16-bit fine adjustment, closed → open
3
0 - 49
50 - 200
201 - 210
211 - 255
Strobe
No strobe
Strobe, slow → fast
No strobe
Random strobe, slow → fast
4
0 - 255
Strobe duration
0 → 1 second
5
0
1 - 255
FX selection
No FX: output controlled on RGB channels
FX selection (see “Pre-programmed FX” on page 35)
6
0 - 126
127 - 128
129 - 255
FX speed / modifier (depending on effect)
Fast → slow
Stop
Slow → fast
7
0
1
2
3 - 34
35
36
37 - 100
101 - 120
121 - 140
141 - 255
FX synchronization
No sync
Fixture offset 10°
Fixture offset 10°
...
Fixture offset 350°
Synchronized
No function (reserved for future use)
Random start
Random duration
No function (reserved for future use)
Segment control
8
0 - 255
Segment 1 Red
0 → 100%
9
0 - 255
Segment 1 Green
0 → 100%
10
0 - 255
Segment 1 Blue
0 → 100%
11
0 - 255
Segment 2 Red
0 → 100%
12
0 - 255
Segment 2 Green
0 → 100%
13
0 - 255
Segment 2 Blue
0 → 100%
Etc...
... ...
Channels used for RGB control of segments:
• 320 mm fixtures (two 160 mm segments) = channels 8 - 13
• 1280 mm fixtures (eight 160 mm segments) = channels 8 - 31
Table 12: DMX Protocol, Segment Mode
