Martin
®
Exterior Dot-Pro HP User Manual Rev. A 9
Setting up the Exterior Dot-HP Pro
Warning! Read “Safety information” and “Precautions to avoid damage” in the Safety
and Installation manual that is supplied with products and included at the end of this
User Manual before applying power to an Exterior Dot-HP Pro installation.
You can set up the Exterior Dot-HP Pro using a Martin P3 controller, an RDM-compatible DMX
controller or the Martin Companion Windows application running on a PC connected to the data link.
The settings listed in this chapter are all available using both P3 and RDM.
Setting up using a Martin P3 controller
A Martin P3 system allows video to be displayed on an installation that contains Exterior Dot-HP Pro
Dots. When a P3 controller is connected to the installation and the installation is powered on, you can
set up the Dots from the P3 controller. See the P3 System Controller user manual for details.
Setting up using RDM
If you are connected to Exterior Dot-HP Pro Dots via an Ethernet link, you can set up the Dots from a
PC using any RDM-compatible controller via Art-Net. It is possible to use sACN to control Dots, but for
setup you need to use RDM via Art-Net.
Martin Companion
If you are connected to Exterior Dot-HP Pro Dots via an Ethernet link, you can set up the Dots from a
PC using the Martin Companion Windows application via Art-Net. Note that Martin Companion cannot
communicate via sACN.
The Martin Companion software suite for Windows can be downloaded free of charge from the Martin
website at www.martin.com. The Martin Companion software suite will always offer the latest Exterior
Dot-HP Pro features and firmware when your PC is connected to the Internet.
Martin Companion offers the following features:
• Simple PC-based user interface
• Update of product firmware
• RDM configuration and addressing
• Standalone show programming with up to twenty scenes and an option to start the show automatically
when fixtures are powered on.
RDM communication
The Exterior Dot-HP Pro responds to the RDM parameter IDs (PIDs) listed in the table below:
RDM DISCOVERY
DISC_UNIQUE_BRANCH
DISC_MUTE
DISC_UN_MUTE
STATUS INFORMATION
GET
SET
QUEUED_MESSAGE
✓
Get queued messages
STATUS_MESSAGES
✓
Get status/error information
STATUS_ID_DESCRIPTION
✓
Status/error description
CLEAR_STATUS_ID
✓
Clear status/error queue
