Martin
®
Exterior Dot-Pro HP User Manual Rev. A 25
Channel
Resolution
Value
Function
Fade
Default
Value
8 contd.
8-bit
91-92
93-94
95-96
97-98
99-100
101-102
103-104
105-106
107 - 190
191 - 214
215 - 219
220 - 243
244 - 247
248 - 251
252 - 255
Dark Green (LEE 124)
Pure Magenta (Blue + Red LEDs only)
Peacock Blue (LEE 115)
Dark Lavender (LEE 180)
Double CT Orange (LEE 287)
Full CT Orange (LEE 204)
Half CT Orange (LEE 205)
Deep Straw (LEE 015)
No function
Continuous rotation
CW, Fast → Slow
Stop (wheel stops at current color)
CCW, Slow → Fast
Random slots
Fast
Medium
Slow
Snap
0
9
8-bit
0 - 26
27 - 228
229 - 255
P3 Mix
DMX Mode
Color of LEDs is fully controlled by DMX
channels, P3 pixel data is ignored
Mix Mode
At the bottom of the range (27), the output is
pure DMX-controlled.
In-between there is a crossfade between
DMX and P3 Pixels
At the top of the range (228), the output is
pure P3 pixel-controlled
Video Mode
Color of LEDs is controlled by P3 pixels
multiplied with DMX channels. This allows the
DMX channels to "color" the P3 pixel data
Snap
0
10
8-bit
0 - 255
FX Select (see ‘FX list’ on page 29)
FX selection 1 -255
Snap
0
11
8-bit
0 - 126
127 - 128
129 - 255
FX Adjust
Reversed Fast → Slow
Stop
Forwards Slow → Fast
Fade
128
12
8-bit
0
1 - 35
36
37 - 100
101 - 120
121 - 140
141 - 255
FX Synchronization
No sync
Dot offset (Shift from 10 – 350 degrees)
Synchronized
No function
Random start
Random duration
No function
Snap
36
