10 TECHNICAL SPECIFICATIONS
WX3A
INPUTS 2 Electronically Balanced
IMPEDANCE 36K ohms (18K ohms per leg single ended)
CMRR 67dB 20-10KHz
CONNECTORS 3 Pin female XLR
OUTPUTS 4 Electronically Balanced
SOURCE IMPEDANCE 47 ohms
MIN LOAD IMPEDANCE 500 ohms
MAX OUTPUT +20dBu into 500 ohms limiter defeated
CONNECTORS 3 Pin Male XLR
FREQUENCY RESPONSE -3dB @ 25 Hz 12dB / octave
-3dB @ 35KHz 12 dB / octave
(ultimately set by system parameters)
DISTORTION+NOISE 0.009% THD @ 2V output (limiters cancelled)
SIGNAL+NOISE/ >97dB’s @ 2V output 20Hz – 20KHz quasi
NOISE RATIO peak o/c input
LIMITERS Individual for each channel. With program
related attack times. Ratio 20:1. Threshold
range -12dBu to +12dbu, in 16 steps
INDICATORS 2-way stereo, 3/4 way-mono LED’s. Signal
present, threshold and LED’s on each band
PROTECTION Auto muting relays and soft start (4 seconds)
MAINS SUPPLY IEC mains connector with integral fuse holder
MAINS VOLTAGE Externally selectable on IEC inlet 100-120-220-
240V AC, 50/60Hz. Voltage tolerance on each
setting ±10%
MAINS FUSE 220-240V: -250mA Type ‘T’(L)
100-120V: -500mA Type ‘T’(L)
DIMENSIONS (W) 482mm x (H) 44mm x (D) 211mm
(W) 19ins x (H) 1.75ins x (D) 8.3ins
WEIGHT 3.5kg (7.7lbs)
SHIPPING DIMENSIONS (W) 530mm x (H) 120mm x (D) 310mm
(W) 21ins x (H) 4.7ins x (D) 12.2ins
SHIPPING WEIGHT 4.1kg (9lbs)
Due to our policy of continuous improvement all specifications are subject
to change without notice
Martin Audio – WX3A System Controller
ENGLISH
15
All material © 2007. Martin Audio Ltd. Subject to change without notice.
