6 CONNECTIONS
Each connector panel has two Neutrik Speakon connectors (NL4 for WT15
and WT2, NL8 for WT3) wired in parallel with each other. The second
connector allows use of a short link lead to power another parallel
loudspeaker. The connectors are wired as follows:
NL4 Pin WT15 - Inputs switchable
1- Input 1 -ve
1+ Input 1 +ve
2- Input 2 -ve
2+ Input 2 +ve
NL4 Pin
WT2 Passive WT2 Active
1- Input -ve Low -ve
1+ Input +ve Low +ve
2- N/C High -ve
2+ N/C High +ve
NL8 Pin
WT3 Bi-amp WT3 Tri-amp
1- Low -ve Low -ve
1+ Low +ve Low +ve
2- Mid/High -ve Mid -ve
2+ Mid/High +ve Mid +ve
3- N/C High -ve
3+ N/C High +ve
4- N/C N/C
4+ N/C N/C
Martin Audio – WAVEFRONT THEATRE SERIES
ENGLISH
6
All material © 2007. Martin Audio Ltd. Subject to change without notice.
