10 TECHNICAL SPECIFICATIONS
WT15
TYPE Ultra-compact, two-way ICT™
FREQUENCY RESPONSE 120Hz-20kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 80Hz
DRIVERS 1 x 5" (125mm) full-range ICT™driver
1 x 5" (125mm) bass/mid driver
RATED POWER 75W AES, 300W peak
RECOMMENDED AMPLIFIER 50-100W into 4 ohms (16 ohms)
SENSITIVITY 91dB 1 Watt/1metre
MAXIMUM SPL 108dB continuous, 114dB peak
IMPEDANCE Externally switchable 4 or 16 ohms
DISPERSION 80 degs horizontal, 80 degs vertical (-6dB)
CONNECTORS 2 x Neutrik Speakon NL4MP
Input externally switchable between pins 1&2
FITTINGS 2 x 3/8" flush mounted nut plates on base
and top
2 x M4 inserts for Omnimount 50
DIMENSIONS (W) 172mm x (H) 282mm x (D) 172mm
(W) 6.8ins x (H) 11ins x (D) 6.8ins
WEIGHT 5kg (11lbs)
SHIPPING DIMENSIONS (W) 390mm x (H) 370mm x (D) 200mm
(Packed in pairs) (W) 15.4ins x (H)14.5ins x (D) 7.9ins
SHIPPING WEIGHT 9kg (19.8lbs)
(Packed in pairs)
Martin Audio – WAVEFRONT THEATRE SERIES
ENGLISH
9
All material © 2007. Martin Audio Ltd. Subject to change without notice.
