WT3
TYPE Compact 3-way trapezoidal, switchable
bi-amp/tri-amp
FREQUENCY RESPONSE 55Hz-18kHz ±3dB
LOW FREQUENCY LIMIT -10dB @ 45Hz
DRIVERS 15" (380mm) dia. / 3" (75mm) voice coil
6.5" (165mm) horn loaded mid-range
1" (25mm) exit HF compression driver
RATED POWER LF: 500W AES, 2000W peak
MF/(MF+HF bi-amp): 150W AES, 600W peak
HF: 60W AES, 240W peak
RECOMMENDED AMPLIFIER 400-800W into 4 ohms
SENSITIVITY LF: 100dB 1 Watt/1 metre
MF/(MF+HF bi-amp): 107dB 1 Watt/1 metre
HF: 105dB 1 Watt/1 metre
MAXIMUM SPL 127dB continuous, 133dB peak
IMPEDANCE LF: 8 ohms nominal
MF/(MF+HF bi-amp): 16 ohms nominal
HF: 16 ohms nominal
DISPERSION 65 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER Bi-amp 650Hz, 3.3kHz internal passive
Tri-amp 650Hz, 4kHz
CONNECTORS 2 x Neutrik Speakon NL8MPR
FITTINGS 8 x M8 threaded inserts
1 x pole mounting socket
2 x MAN blanking plates
2 x rear kelp fittings
2 x front lid fittings
DIMENSIONS (W) 435mm x (H) 708mm x (D) 425mm
(W) 17.1ins x (H) 27.9ins x (D) 16.7ins
WEIGHT 32kg (70.5lbs)
SHIPPING DIMENSIONS (W) 550mm x (H) 790mm x (D) 550mm
(W) 21.7ins x (H) 31.1ins x (D) 21.7ins
SHIPPING WEIGHT 36kg (79.4lbs)
Due to our policy of continuous improvement all specifications are subject to
change without notice.
Martin Audio – WAVEFRONT THEATRE SERIES
ENGLISH
11
All material © 2007. Martin Audio Ltd. Subject to change without notice.
