WT2
TYPE Compact 2-way trapezoidal, switchable
active/passive
FREQUENCY RESPONSE 70Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 52Hz
DRIVERS 12" (305mm) dia. / 3" (75mm) voice coil
1" (25mm) exit HF compression driver
RATED POWER LF/FR: 400W AES, 1600W peak
HF: 60W AES, 240W peak
RECOMMENDED AMPLIFIER 400-600W into 4 ohms
SENSITIVITY LF/FR: 98dB 1 Watt/1 metre
HF: 107dB 1 Watt/1 metre
MAXIMUM SPL 123dB continuous, 129dB peak
IMPEDANCE FR, LF & HF: 8 ohms nominal
DISPERSION 70 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 2kHz active or internal passive
CONNECTORS 2 x Neutrik Speakon NL4MPR
FITTINGS 8 x M8 threaded inserts
1 x pole mounting socket
2 x MAN blanking plates
2 x rear kelp fittings
2 x front lid fittings
DIMENSIONS (W) 365mm x (H) 554mm x (D) 364mm
(W) 14.4ins x (H) 21.8ins x (D) 14.3ins
WEIGHT 24.5kg (54lbs)
SHIPPING DIMENSIONS (W) 460mm x (H) 660mm x (D) 460mm
(W) 18.1ins x (H) 26ins x (D) 18.1ins
SHIPPING WEIGHT 24kg (52.9lbs)
Martin Audio – WAVEFRONT THEATRE SERIES
ENGLISH
10
All material © 2007. Martin Audio Ltd. Subject to change without notice.
