W1
TYPE Ultra-compact 2-way passive trapezoid
FREQUENCY RESPONSE 75Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 55Hz
DRIVERS 10” (250mm) LF
1” (25mm) exit HF compression driver
RATED POWER 150W AES, 600W peak
RECOMMENDED AMPLIFIER 300-400W into 4 ohms
SENSITIVITY 97dB
MAXIMUM SPL 118dB continuous, 124dB peak
IMPEDANCE 8 ohms nominal
DISPERSION 70 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 2.2kHz, passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 12 x M8 threaded inserts
1 x pole mounting socket
DIMENSIONS (W) 335mm x (H) 487mm x (D) 325mm
(W) 13.2ins x (H) 19.2ins x (D) 12.8ins
WEIGHT 14.5kg (32lbs)
SHIPPING DIMENSIONS (W) 420mm x (H) 600mm x (D) 420mm
(W) 16.5ins x (H) 23.6ins x (D) 16.5ins
SHIPPING WEIGHT 16kg (35.3lbs)
Martin Audio – WAVEFRONT PROFESSIONAL SERIES
ENGLISH
9
All material © 2007. Martin Audio Ltd. Subject to change without notice.
