W3
TYPE Compact bi-amplified 3-way trapezoid
FREQUENCY RESPONSE 55Hz-18kHz ± 3dB
LOW FREQUENCY LIMIT -10dB @ 45Hz
DRIVERS 15” (380mm) / 3” (75mm) voice coil
6.5” (165mm) horn loaded mid-range
1” (25mm) exit HF compression driver
RATED POWER LF: 400W AES, 1600W peak
MF/HF: 150W AES, 600W peak
RECOMMENDED AMPLIFIER 400-600W into 4 ohms
SENSITIVITY LF: 100dB
MF/LF: 104dB
MAXIMUM SPL 125dB continuous, 131dB peak
IMPEDANCE LF: 8 ohms nominal
MF/HF: 16 ohms nominal
DISPERSION 65 degs horizontal, 40 degs vertical (-6dB)
CROSSOVER 650Hz active, 3.3kHz internal passive
CONNECTORS 2 x Neutrik Speakon NL4
FITTINGS 8 x M8, 4 x M6 threaded inserts
1 x pole mounting socket
2 x MAN blanking plates
2 x rear kelp fittings
DIMENSIONS (W) 435mm x (H) 708mm x (D) 425mm
(W) 17.1ins x (H) 27.9ins x (D) 16.7ins
WEIGHT 31.5kg (69lbs)
SHIPPING DIMENSIONS (W) 550mm x (H) 790mm x (D) 550mm
(W) 21.7ins x (H) 31.1ins x (D) 21.7ins
SHIPPING WEIGHT 36kg (79.4lbs)
Martin Audio – WAVEFRONT PROFESSIONAL SERIES
ENGLISH
11
All material © 2007. Martin Audio Ltd. Subject to change without notice.
