10 TECHNICAL SPECIFICATIONS
SCREEN 2
DRIVERS 1 x 15" (380mm) low frequency
1 x 1" (25mm) exit HF compression driver
FREQUENCY RESPONSE 45Hz-20kHz ± 3dB
RATED POWER LF: 550W AES, 2200W peak
HF: 60W AES, 240W peak
SENSITIVITY LF: 98dB 1 Watt/1 metre
HF: 110dB 1 Watt/1 metre
CROSSOVER 1.2kHz
IMPEDANCE LF: 8 ohms
HF: 8 ohms
DISPERSION 90 degs horizontal x 90 degs vertical
DIMENSIONS LF: (W) 650mm x (H) 765mm x (D) 307mm
(W) 25.6ins x (H) 30.1ins x (D) 12.8ins
HF: (W) 285mm x (H) 344mm x (D) 185mm
(W) 11ins x (H) 13.4ins x (D) 7.1ins
WEIGHT LF: 39kg (86lbs)
HF: 4.5kg (9.9lbs)
SHIPPING DIMENSIONS (W) 700mm x (H) 1000mm x (D) 350mm
(W) 27.6ins x (H) 39.4ins x (D) 13.7ins
SHIPPING WEIGHT 47kg (103.6lbs)
Martin Audio – CINEMA SERIES
ENGLISH
10
All material © 2007. Martin Audio Ltd. Subject to change without notice.
