SCREEN 4
DRIVERS 2 x 15" (380mm) low frequency
1 x 6.5" (165mm) mid horn
1 x 1" (25mm) HF compression driver
FREQUENCY RESPONSE 45Hz-20Hz ± 3dB
RATED POWER LF: 800 AES, 3200W peak
MF/HF:150W AES, 600W peak
SENSITIVITY LF: 100dB 1 Watt/1 metre
MF/HF: 106dB 1 Watt/1 metre
CROSSOVER 630Hz (active or passive), 3kHz passive
IMPEDANCE LF: 4 ohms
MF/HF: 16 ohms
DISPERSION 90 degs horizontal x 40 degs vertical
DIMENSIONS LF: (W) 670mm x (H) 1010mm x (D) 470mm
(W) 26.4ins x (H) 39.8ins x (D)18.5ins
MF/HF: (W) 490mm x (H) 385mm x (D) 290mm
(W) 19.3ins x (H) 15.2ins x (D) 11.4ins
WEIGHT LF: 61kg (134.5lbs)
MF/HF: 9kg (19.8lbs)
SHIPPING DIMENSIONS LF: (W) 670mm x (H) 1030mm x (D) 490mm
(W) 26.4ins x (H) 40.6ins x (D)19.3ins
MF/HF: (W) 610mm x (H) 520mm x (D) 380mm
(W) 24ins x (H) 20.5ins x (D) 15ins
SHIPPING WEIGHT LF: 70kg (154.3lbs)
MF/HF: 9kg (19.8lbs)
Martin Audio – CINEMA SERIES
ENGLISH
11
All material © 2007. Martin Audio Ltd. Subject to change without notice.
