Martin Audio – MA900 Amplifier
ENGLISH
16
12 SPECIFICATIONS MA900
MAXIMUM OUTPUT POWER EIA @1kHz 1%thd FTC 20 – 20kHz @ 0.1% thd
8Ω per Channel
300W 280W
4Ω per Channel
500W 460W
2Ω per Channel
700W 660W
8Ω Bridged
1000W 920W
4Ω Bridged
1400W 1320W
MAXIMUM OUTPUT VOLTAGE
8Ω load 49Vrms
Peak voltage, no load 77Vrms
POWER REQUIREMENTS 230V version 115V version
Operating voltage 130 – 265 Vac 65 – 135Vac
Minimum start up voltage 190Vac 95Vac
Peak inrush current 20A 10A
MAINS CURRENT DRAW @ 4 Ohms 230V version 115V version
Quiescent current (no load) 0.6Arms 1.2Arms
1/8
th
Full power (both channels driven) 3.5Arms 7Arms
1/3
rd
Full power (both channels driven) 5.5Arms 11Arms
Full power (1Khz @1% thd) 9.5Arms 19 Arms
DISTORTION
THD 20Hz – 20KHz 1W to full power 0.03%
THD @ 1KHz 1dB below clip 0.005%
DIM 30 @ 3dB below clip 0.008%
HUM / NOISE < - 105dB
CHANNEL SEPERATION -70dB
OUTPUT IMPEDANCE 30mΩ
SLEW RATE 45VµS
INPUTS
DIP switch selectable gain dB
Input Vrms Ref 4Ω for full power
Impedance 20KΩ Differential
10KΩ Single ended
c.m.r.r 50dB
DIMENSIONS (W) 483mm x (H) 88mm x (D) 359mm
(W) 19ins x (H) 3.5ins x (D) 14.1ins
WEIGHT 15Kg (33Ibs)
SHIPPING DIMENSIONS (W) 560mm x (H) 180mm x (D) 500mm
(W) 22ins x (H) 7.1ins x (D) 19.7ins
SHIPPING WEIGHT 16.6Kg (36.5lbs)
20 23 26 29 32 35 38 41
3.58 2.53 1.79 1.27 0.90 0.64 0.45 0.32
All material © 2007. Martin Audio Ltd. Subject to change without notice.
<
>
