Martin Audio – MA200Q Amplifier
ENGLISH
18
12 SPECIFICATIONS MA200Q
MAXIMUM OUTPUT POWER EIA @1kHz 1%thd FTC 20 – 20kHz @ 0.1% thd
8Ω per Channel
130W 120W
4Ω per Channel
200W 180W
2Ω per Channel
270W 245W
8Ω Bridged
400W 360W
4Ω Bridged
540W 490W
MAXIMUM OUTPUT VOLTAGE
8Ω load 32Vrms
Peak voltage, no load 51Vrms
POWER REQUIREMENTS 230V version 115V version
Operating voltage 130 – 265 Vac 65 – 135Vac
Minimum start up voltage 180Vac 90Vac
Peak inrush current 10A 20A
MAINS CURRENT DRAW @ 4 Ohms 230V version 115V version
Quiescent current (no load) 0.6Arms 1.2Arms
1/8
th
Full power (both channels driven) 2.9Arms 6Arms
1/3
rd
Full power (both channels driven) 4.5Arms 9Arms
Full power (1Khz @1% thd) 7.9Arms 16Arms
DISTORTION
THD 20Hz – 20KHz 1W to full power 0.05%
THD @ 1KHz 1dB below clip 0.01%
DIM 30 @ 3dB below clip 0.008%
HUM / NOISE < - 105dB
CHANNEL SEPERATION -70dB
OUTPUT IMPEDANCE 30mΩ
SLEW RATE 30VµS
INPUTS
Fixed gain dB 32
Input Vrms Ref 4Ω for full power
4 x Single Channel 0.71
Impedance 20KΩ Differential
10KΩ Single ended
c.m.r.r. 50dB
DIMENSIONS (W) 483mm x (H) 88mm x (D) 325mm
(W) 19ins x (H) 3.5ins x (D) 12.8ins
