5. Fan grille filter

A foam filter is located behind the front panel grille to prevent dust entering

the amplifier.

6. Power switch

This is used to power up the amplifier.

(See page 7 and 15)

4.2 The rear panel

Figure 2. Rear panel

1. Speakon connector

This type of speaker connector may be unfamiliar to some users. A full

description is found in the operation section. (See page 11).

2. Minimum load selector (MLS™) switch

This switch is used to select the minimum nominal speaker impedance the

amplifier is going to drive (see page 12).

3. Clip limiter switch

Turns the clip limiter on and off. (See page 17).

4. Input jack

Alternative to using input XLR or for linking inputs with other amplifiers.

(See page 9).

5. Input signal XLR (See page 8).

6. Polarity reverse switch for channel B

For reversing the input signal polarity of channel B to allow bridged

operation. (See page 13).

7. Input link switch

Allows a single input to drive both channels simultaneously. (See page 13).

8. Gain select switch

Allows amplifier gain to be switched between 32dB (1.55Vrms input

sensitivity) and 38dB gain (0.775mV input sensitivity). (See page 16).

9. AC power cable (See page 6).

Martin Audio – MA2.8 Power Amplifier

ENGLISH

➀

➂

➁

➂

➁

➃

➄

➅

➆

➇

➀

➈
