7.3 Specification

POWER REQUIREMENTS

Power supply................................................................................................115-230V (-15%, +15%) (50/60Hz)

Power factor.........................................................................................more than 0.95 from 500W to full power

Operating temperature .................................................................................................................... 0° C, 45° C

Weight........................................................................................................................................ 12Kg (26.5 lbs)

External dimensions

Width……………………………………………………………………..……..…..Standard 19” Rack: 483mm (19”)

Depth…………..………………………………………….………………………………………………475mm (18.7”)

Height…………………………………………………….…………………………………1 Rack Unit: 44mm (1.75”)

AUDIO SECTIONS

Bandwidth (1W, 8Ohm)......................................................................................................20Hz, 20KHz ±0,2dB

Damping factor (8Ohm)................................................................................................... (20Hz, 200Hz) > 5000

Slew Rate (8Ohm)................................................................................................50V/uS (input filter bypassed)

S/N ratio.......................................................................................................................................................>110

Distortion THD……………………………………….…..... Max < 0.5% from 1W to full power (typically < 0.05%)

Intermodulation SMPTE …………………………....……. Max < 0.5% from 1W to full power (typically < 0.05%)

Intermodulation DIM 30.................................................... Max<0.5% from 1W to full power (typically < 0.05%)

Inputs............................................................................................Balanced to ground, XLR female combo jack

Impedance..............................................................................................10KOhm each leg balanced to ground

Gain ……………………………………..…………….….…………………...…....26, 29, 32, 35dB, user selectable

Outputs….……...…...High current Neutrik 4-pole Speakon connectors (pins 1+ 2+ paralleled, 1-2- paralleled)

Data……………………………………………………………………………………………..………RS485 via RJ45

OUTPUT SPECIFICATIONS

Output Power

EIAJat 1KHz, 1% THD

8Ω Per Channel………….……………………………………………………………………………………….2700W

4Ω Per Channel………….……………………………………………………………………………………….5200W

2Ω Per Channel…………………………………………………………………………………………………..9000W

16Ω Bridged……………………………………………………………………………………………………….5400W

8Ω Bridged………………………………………………………………………………………………….……10400W

4Ω Bridged……………………………………………………………………………………………………....18000W

Max output voltage……………………………………………………………………………………………….…225V

Max output current……………………………………………………………………………………………...…102A

FEATURES

Display…………………………………………………………………………………. LCD matrix interactive display

Indicators…………………………………………………………..……2 x Multi-function 7 segment LED bargraph

Data Storage and Transfer…………...........................................................…………………Smart Card Reader
