Introduction
The Martin Audio iK41 advanced system amplifier
represents current state-of-the-art technology in a
number of areas. This product is the result of several
years of research, from which many advances in switched
mode power technologies and ever finer detail in signal
processing have stemmed. Taking advantage of the latest
advances in analogue to digital conversion technologies,
the unit achieves performance levels among the very best
that current technology permits.
Key features
▪ Four channels of sonically pure Class D amplification
▪ Very high power density in 2U rack space
▪ Up to 6,000watts total power output, depending on
load impedance
▪ Packed with robust protection and monitoring systems
to keep the show going
▪ External Breaker Protection (EBP) limits the current
draw to prevent breakers opening
▪ Martin Audio minimal signal path design
▪ Class leading sonic performance achieved by the use
of state-of-the-art amplifier technologies and highly
advanced DSP algorithms using Linea Micro Detail
(LMD)
▪ High performance 96kHz DSP on all inputs and
outputs
▪ Up to 1,000 FIR filter taps at 48kHz on each output
channel (reserved for optimised systems)
▪ High speed Ethernet communications supporting
DHCP, static IP and auto IP and direct connection to
a computer without the need for a router or a switch
▪ Powerful Drive Module concept, abstraction from
device centric to speaker-based control
▪ Innovative Component Presets to allow individual
outputs to be used for selected drivers of a
loudspeaker system
▪ Unique VX limiter providing dynamic control for passive
two-way enclosures
▪ Unique LIR crossover shapes giving FIR-like
performance without the drawbacks
▪ Linear phase HF system EQ profiling which provides
perfect integration between enclosures
▪ Innovative excursion control limiter with sliding High
Pass Filter; limits only the damaging low frequencies
▪ Transducer thermal modelling provides regulation
limiters, addressing long term overload
▪ Overshoot limiter governs amplitude of transient
signals retaining average power whilst constraining
peak energy
▪ Analogue, AES3 and Dante (AES67 compatible) inputs
▪ Automatic fallover from digital inputs
Other iKONs
There are three amplifiers in the iKON range and the
only differences are total power output and number of
channels:
iKON Channels Power
1
iK42 4 20,000 watts
iK81 8 10,000 watts
iK41 4 6,000 watts
1
The total power output depends on the load impedance
For details of the other iKON amplifiers, go to our website
martin-audio.com.
Drive modules
The iK41 processor uses Drive Modules to order
and group channels using a speaker-based approach
to controlling, designing and recalling speaker
configurations. A Drive Module is the processing provided
by one input DSP block and a number of output DSP
blocks. These blocks are associated by routing. For
example, if input DSP block B is routed to outputs
3 and 4, then this is a two-way Drive Module with
input DSP block B forming the ‘Master’ control, and
output DSP blocks 3 and 4 providing the driver-related
control. Overall, this forms the processing typically for one
loudspeaker sub-system. You can use Vu-Net (page 36)
to control and monitor the associated speaker.
The presets in the device are Drive-Module centric and
are used to configure individual Drive Modules rather
than the whole device. Importantly, Drive Modules move
the focus away from the processing device and onto
the loudspeaker systems. A Drive Module preset can be
broken into components, allowing any output to be used
iK41 User Guide
6
