Martin Audio – DX1 Speaker Management System
ENGLISH
26
Appendix 3
Factory Preset File
version 1.2, 19th June 2002
Preset
number
Loudspeaker system Configuration Input A Input B Output 1 Output 2 Output 3 Output 4 Output 5 Output 6
WAVEFRONT
20 W8+WSX 3 WAY PASSIVE 2x3 way o/p 1 to 3 o/p 4 to 6 Low Lomid Midhi Low Lomid Midhi
21 W8+WSX 4 WAY ACTIVE 1x4 way o/p 1 to 4 o/p 5 to 6 Low Lomid Himid High Aux Aux
22 W8+W8S OR CS 3 WAY PASSIVE 2x3 way o/p 1 to 3 o/p 4 to 6 Low Lomid Midhi Low Lomid Midhi
23 W8+W8S OR CS 4 WAY ACTIVE 1x4 way o/p 1 to 4 o/p 5 to 6 Low Lomid Himid High Aux Aux
24 W8+W8S 5 WAY ACTIVE 1x5 way o/p 1 to 5 o/p 6 Low18 Low15 Lomid Himid High Aux
25 W8+WSX 4 WAY ACTIVE HF LIFT 1x4 way o/p 1 to 4 o/p 5 to 6 Low Lomid Himid High Aux Aux
26 W8 LONGTHROW+WSX 1x4 way o/p 1 to 4 o/p 5 to 6 Low Lomid Himid High Aux Aux
27 W1/W2PASSIVE/W3P 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
28 W1/W2 PASSIVE/W3P+WS2A 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
29 W2 ACTIVE 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
30 W2 ACTIVE+WS2A 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
31 W2 ACTIVE+W8CS 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
32 W3 2x2 way o/p 1 & 2 o/p 3 & 4 Low Midhi Low Midhi Sum A+B Sum A+B
33 W3+WS2A 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
34 W3+W8CS 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
35 W3+WSX 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
36 WT2 PASSIVE 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
37 WT2 PASSIVE+WS2A 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
38 WT2 ACTIVE 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
39 WT2 ACTIVE+WS2A 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
40 WT2 ACTIVE+W8CS 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
41 WT3 BIAMP 2x2 way o/p 1 & 2 o/p 3 & 4 Low Midhi Low Midhi Sum A+B Sum A+B
42 WT3 BIAMP+WS2A 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
43 WT3 BIAMP+W8CS 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
44 WT3 BIAMP+WSX 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
45 WT3 TRIAMP 2x3 way o/p 1 to 3 o/p 4 to 6 Low Mid High Low Mid High
46 WT3 TRIAMP+WS2A 1x4 way o/p 1 to 4 o/p 5 to 6 Sub Low Mid High Aux Aux
47 WT3 TRIAMP+W8CS 1x4 way o/p 1 to 4 o/p 5 to 6 Sub Low Mid High Aux Aux
48 WT3 TRIAMP+WSX 1x4 way o/p 1 to 4 o/p 5 to 6 Sub Low Mid High Aux Aux
LE SERIES
49 LE 400B/C 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
50 LE 700/A 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
51 LE12J BIAMP 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
BLACKLINE
52 F8 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
53 2xF8+MONO S12 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
54 F10 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
55 F10+S12 OR MONO S15/S18 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
56 F12/F15 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
57 F12/F15+S15/S18 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
58 2xF12/F15+S218 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
59 F15A 2x2 way o/p 1 & 2 o/p 3 & 4 Low High Low High Sum A+B Sum A+B
60 F15A+S15/S18 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
61 2xF15A+S218 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low High Sub Low High
62 F215 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
63 F215+S18 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
64 F215+S218 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
65 H2 PASSIVE+S218 2x2 way o/p 1 & 2 o/p 3 & 4 Low Midhi Low Midhi Sum A+B Sum A+B
66 H2 ACTIVE+S218 2x3 way o/p 1 to 3 o/p 4 to 6 Low Mid High Low Mid High
67 H3 2x2 way o/p 1 & 2 o/p 3 & 4 Low Midhi Low Midhi Sum A+B Sum A+B
68 H3+S218 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
69 H3T 2x3 way o/p 1 to 3 o/p 4 to 6 Low Mid High Low Mid High
70 H3T+S218 1x4 way o/p 1 to 4 o/p 5 to 6 Sub Low Mid High Aux Aux
EM SERIES
71 EM 15,26,56,76 2x2 way o/p 1 & 2 o/p 3 & 4 FR Aux FR Aux Sum A+B Sum A+B
72 EM 186 2x2 way o/p 1 & 2 o/p 3 & 4 Low Midhi Low Midhi Sum A+B Sum A+B
73 EM 15,26,56,76+EM 150/201/251 2x2 way o/p 1 & 2 o/p 3 & 4 Sub HPass Sub HPass Msub Sum A+B
74 EM 186+EM201/251 2x3 way o/p 1 to 3 o/p 4 to 6 Sub Low Midhi Sub Low Midhi
Outputs marked 'Aux' or 'Sum A+B' can be configured by the user, please see 'Configuring the DX1 manually' for further explaination.
The default settings for the 'Aux' and 'Sum A+B' outputs are 'flat', i.e. no filters, parametric eq, gain or delay.
Outputs marked 'Msub' are the mono equivalent of the respective Sub outputs and are not user configurable.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
