on stage. This would give a far better experience on
stage for the musicians or DJ and eliminate problematic
reflections off rear walls.
The SXC115 requires two channels of amplification, one
channel for the front facing driver and one for the
rear facing driver, both of which require independent
processing. The system uses a DX0.6 to provide the
processing required with channels 1 and 2 for the front
and rear processing for the left sub, channels 3 and 4 for
the right sub and channels 5 and 6 for the left and right
X12 speakers.
The system uses three Martin Audio amplifiers:
Two VIA5002 amplifiers, one for each of the SXC115
subs.
One VIA2502 amplifier for the two X12 speakers.
Short XLR leads connect the DX0.6 to the amplifiers.
Outputs 1 and 2 go to inputs 1 and 2 of the first VIA5002.
Outputs 3 and 4 go to inputs 1 and 2 of the second
VIA5002. Outputs 5 and 6 go to inputs 1 and 2 of the
VIA2502.
The outputs from the VIA5002 amplifiers use a single
4-core NL4 speaker lead connected to output 1. This has
channel 1 on pins 1+/- and channel 2 on pins 2+/- so that
the two independent channels are fed to each subwoofer
down a single cable. The outputs from the VIA2502 are
standard NL4 speaker cables with output 1 to one X12
and output 2 to the other X12.
To configure the DX0.6 output channels, use the presets
for the SXC115 front on channels 1 and 3, SXC115 rear
on channels 2 and 4 and X12 on output channels 5 and
6. For fully stereo operation, route input A to outputs 1,
2 and 5 and input B to outputs 3, 4 and 6. You could
configure the subwoofers in mono. In this case, route
input channel A to outputs 1, 2, 3, 4 and 5 and input
B to outputs 1, 2, 3, 4 and 6.
DX0.4 User Guide
33
