Martin Audio – C516 Ceiling Loudspeaker
ENGLISH
8
8 TECHNICAL SPECIFICATIONS
C516
TYPE Ceiling Mounted, two-way ICT™
vented baffle
FREQUENCY 80Hz – 20kHz
RESPONSE 120Hz – 20kHz ± 3dB
DRIVER 1 x 6.5" (160mm) full-range ICT™
RATED POWER 50W AES, 200W peak
RECOMMENDED 50-200W into 4 ohms
AMPLIFIER
SENSITIVITY 88dB (1 watt @ 1 metre)
MAXIMUM SPL 105dB continuous, 111dB peak
IMPEDANCE 4 ohms
DISPERSION (-6dB) 90 degree conical
FINISH Bezel & grille – white
PROTECTIVE GRILLE Expanded metal mesh
CONNECTORS 20mm gland in backcan
OPTIONS 30w line transformer
Tile support rails
DIMENSIONS (OD) 240mm x (D) 180mm
(OD) 9.6ins x (D) 7.1ins
WEIGHT C516 2kg (4.4lbs)
WEIGHT C516T 2.7kg (6lbs)
SHIPPING DIMENSIONS (W) 300mm x (H) 200mm x (D) 300mm
(W) 11.8ins x (H) 7.9ins x (D) 11.8ins
SHIPPING WEIGHT C516 2.5kg (5.5lbs)
SHIPPING WEIGHT C516T 3.2kg (7.1lbs)
Due to our policy of continuous improvement all specifications are subject
to change without notice.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
