BlacklineX USERGUIDE

BlacklineXUserGuideV2.1 27



…………

DX0.5

Introduc tion

Offering sophisticated EQ, crossover, dynamics processing and system protection, the Martin Audio DX0.5 Loudspeaker

ManagementSystemprovidescompletesystem optimizationfor bothpassiveandpowered systems.Five different operating

modescoverawiderangeofsystems.Eachofthesixoutputsfeaturededicatedlevelcontrol,mute,polarityinvert,high/low‐

passfilters,7‐ban

dparametric/shelvingEQ,600msdelay andlimiting.Twoinputchannelsprovideindependentlevelcontrol,

mute,600msdelayandaflexible5‐bandparametric/shelvingEQ.Theconvenientfront‐panelcontrolalsoincludes7‐segment

LED metering per channel. The DX0.5 utilizes high‐end 24‐bit AK

M® AD/DA converters with120 dB dynamic range forclass‐

leadingsoundquality.With24user‐definablepresetsandflexibleI/Oforsimpleroutingandconfiguration,theDX0.5isanultra‐

flexibleprocessor,idealforawiderangeofportableandpermanentapplications.

Features

 Professional2‐input,6‐outputsystemprocessorforpassiveandpoweredLoudspeakersystems

 Sophisticated,intuitiveEQ,crossover,delayanddynamicsprocessingoptimizesandprotectsyoursystem

 High‐end24‐bitAKM®AD/DAwith120dBdynamicrange

 TwobalancedXLRinputswithlevelcontrol,mute,600msdelayand5‐bandparametric/sh

elvingEQ

 SixbalancedXLRoutputswithlevelcontrol,mute,polarityinvert,dedicatedhighandlowpassfilters,7‐bandparametric

/shelvingEQ,600msdelay,andlimiting

 Powerfullimiteroneveryoutputforultimateprotection

 Convenientfront‐panelcontrolsforparametereditingandin

put/outputmuting

 USBportforsimpleprogrammingviaPC

 Linkableinputsandoutputsforeasystereoconfiguration

 7‐segmentLEDmeteringforinput/outputlevelorlimiteractivity

 5operatingmodes:2xstereo+sub,3xstereo,2x2‐way+sub,2x3‐wayand1x6‐way

 24presetsforst

oringMartinAudioBlacklineXorothersystemparameters 

 Switchmodepowersupply:100V–240V

 Compact,singlerackunitdesignsystemcontrollermayalsobeusedasasimpleequaliserandlimiterforf

ullypassive

full‐range

RearPanel



1.Power

Usethisrocker‐styleswitchtoturntheunitonoroff.Theprocessorisonwhenthetopoftheswitchispressedin.Itisoffwhen

thebottomoftheswitchispressedin.TheLCDDisplay[6]willilluminateandtextwillappearwhenthepowerswitchison.

The DX0.5 rem

embers its settings, so you may power cycle the unit and it will resume operation using thesame settings as

before.The DX0.5employsrelaysontheoutputstopreventunwantedpopsandnoiseinthesystemwhenpowercyclin gand

startinguptheprocessor.Afterengagingthepowerswitch

,theunitwillinitializeandtherelayswillswitch.Anyliveoutputswill

smoothlyfadefromsilencetotheirconfiguredoutputlevels.Theprocessormaynowbeedited,oritisreadyforuseiftheDX0.5

isalreadyconfiguredfortheloudspeakersystemundercontrol.

2.PowerLeadSocketandFuse

Thisiswheretoconnectthedetachablepowercableincludedwiththeprocessor.Plugtheotherendofthepowerleadintoan

ACoutlet.Theoutletshouldmatchthepowercable.
