All material © 2007. Martin Audio Ltd. Subject to change without notice.
presets are available as binary files from www.martin-audio.com for loading via a pc.
Please refer to the DX2 user’s guide for further information.
8.4 Engineer Installed system digital management processor
The Martin Audio Engineer 4in/8out and 8in/8out digital management processors provide comprehensive
control and management of installed loudspeaker systems.
In addition to crossover, EQ and limiter functions, Engineer processors offer a flexible event scheduler,
automatic programme level and tonality control to compensate for variations in programme sources and a
unique psycho-acoustical BassCreator algorithm.
BassCreator is capable of extending the perceived range of small loudspeakers 1 to 1½ octaves below the
resonance frequency of a loudspeaker without overloading the loudspeaker and without creating sub-sonic
sound leakage.
Engineer processors are supplied pre-loaded with a limited range of Martin Audio presets. Blackline+
presets will be made available shortly from www.martin-audio.com
for loading via a pc.
A note on the illustrations
Please note that for simplicity only the left channel is shown and each line in the diagram represents a pair
of wires.
The illustrations show systems configured using the cost-effective Martin Audio M3
+
controller. Larger,
zoned systems may require the more comprehensive facilities offered by Martin Audio digital controllers like
the DX1, DX2 or Engineer. See above for details.
The M3
+
controller’s internal crossover card must be properly configured for the system to be used. Please
see the M3
+
configuration notes later in this user guide for further information.
9 System configurations
There are many different system combinations possible with the Blackline
+
Series. Some typical
configurations illustrations are shown below.
Main-to-subwoofer ratios
The number of full-range or mid/high systems required to match the efficiency of one sub-bass system is
shown where applicable.
9.1 Passive systems
F8
+
, F10
+
, F12
+
or F15
+
passive system set-up (F12
+
shown)
The F215
+
may also be used like this – but with an M3
+
F215
+
card in place of the Combo card
The M3
+
front panel and internal Combo card must be set for Full-range operation for this passive,
full-range configuration.
See M3
+
configuration notes later.
