Martin Audio – Blackline Series
ENGLISH
13
F15
TYPE Compact, two way passive multi-angled, vented
FREQUENCY RESPONSE 55Hz-18kHz ±3db
RATED POWER 400W AES, 1600W peak
SENSITIVITY 99dB
MAXIMUM SPL 123dB continuous, 129dB peak
RECOMMENDED AMPLIFIER 400-800W (into 4 ohms)
DISPERSION 80 degs horizontal x 50 degs vertical
NOMINAL IMPEDANCE 8 ohms
BASS 380mm (15")
MID —
HIGH FREQUENCY 35mm (1.4'') exit compression driver
CROSSOVER 1.2kHz passive
ENCLOSURE 68 litre, multi laminate birch ply
FINISH Textured black paint
GRILLE Black perforated steel
CONNECTOR 2 x Neutrik NL4
FITTINGS 12 x M8 inserts. Top hat fitting
DIMENSIONS (W) 470mm x (H) 690mm x (D) 443mm
(W) 18.5ins x (H) 27.2ins x (D) 17.5ins
WEIGHT 32.5kg (71.5lbs)
SHIPPING DIMENSIONS (W) 590mm x (H) 760mm x (D) 560mm
(W) 23ins x (H) 30ins x (D) 22ins
SHIPPING WEIGHT 39kg (85.8lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
