3.1 2-way full-range systems
F12
The F12 is a 2-way full-range system with 12"
(300mm) LF driver and 1" (25mm) exit compression
driver mounted on a rotatable 80 x 50 constant
directivity HF horn. It is ideal for applications which
call for compact size, high output and ease of
transportation. With its multi-angle cabinet shape and
rotatable horn, it can be either tripod mounted or used
as a highly efficient floor monitor. To rotate the horn
for horizontal use, remove the grille (see 3.5 ),
unscrew the horn and rotate it through 90 degrees.
The F12 may be used with or without an
M3 controller.
F15
The F15 delivers impressive and dynamic full-
frequency sound from a compact 2-way speaker.
A powerful 15"(380mm)/3"(76mm) coil bass driver is
teamed with a 1.4" (35mm) exit compression driver
mounted on a rotatable 80 x 50 high frequency horn.
The F15 has a versatile multi-angle enclosure
configurable for vertical or horizontal use and a pole
mount socket is provided for tripod mounting. To
rotate the horn for horizontal use, remove the grille
(See 3.5 below), unscrew the horn and rotate it
through 90 degrees. The F15 may be used with or
without an M3 controller.
3.2 2-way mid/high system
H2
The H2 is the essential mid/high pack for dance club
and live music stages. It features an innovative
Hybrid™ 10" (250mm) mid-range horn with a unique
phase-ball loading device. This maintains the 70 x 40
directivity pattern of the mid horn up to 2kHz where a
1" (25mm) exit HF compression driver takes over.
The H2 has a switchable active/passive 2kHz
crossover network to permit either passive or bi-amp
operation. At the lower end of its range, performance
of the mid extends down to 160Hz.
Martin Audio – Blackline Series
ENGLISH
3
All material © 2007. Martin Audio Ltd. Subject to change without notice.
