Martin Audio – Blackline Series
ENGLISH
14
H2
TYPE Two way passive/active trapezoid Hybrid™
fully horn loaded
FREQUENCY RESPONSE 150Hz-18kHz ±3db
RATED POWER MF/(MF+HF): 300W AES, 1200W peak
HF: 60W AES, 240W peak
SENSITIVITY MF/(MF+HF): 104dB
HF: 106dB
MAXIMUM SPL 127dB continuous, 133dB peak
RECOMMENDED AMPLIFIER MF/(MF+HF): 400-650W (into 4 ohms)
HF: 100-400W (into 4 ohms)
DISPERSION 70 degs horizontal x 40 degs vertical
NOMINAL IMPEDANCE MF/(MF+HF): 8 ohms
HF: 8 ohms
BASS —
MID 250mm (10'')
HIGH FREQUENCY 25mm (1'') exit compression driver
CROSSOVER 150Hz active
2kHz passive/active
ENCLOSURE 75 litre, multi laminate birch ply
FINISH Textured black paint
GRILLE Black perforated steel
CONNECTOR 2 x Neutrik NL4
FITTINGS 12 x M10 inserts. 4 x 100mm castors
DIMENSIONS (W) 561mm x (H) 571mm x (D) 496mm
(W) 22.1ins x (H) 22.5ins x (D) 19.5ins
WEIGHT 35kg (77lbs)
SHIPPING DIMENSIONS (W) 660mm x (H) 670mm x (D) 600mm
(W) 26ins x (H) 26.4ins x (D) 23.6ins
SHIPPING WEIGHT 35kg (77.2lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
