Q218 amplifier compatibility
Amplifier Channels Channels used One speaker per channel (4ohm) Two speakers per channel (2ohm)
iK41 One channel 1 of 4 No No
Two channels bridged 2 of 4 –0.3dB No
iK42 One channel 1 of 4 –0.3dB –1.1dB
Two channels bridged 2 of 4 Yes No
iK81 One channel 1 of 8 No No
Two channels bridged 2 of 8 –1.1dB No
VIA5004 One channel 1 of 4 No No
Two channels bridged 2 of 4 –1.1dB No
VIA2502 One channel 1 of 2 No No
Two channels bridged 2 of 2 –1.1dB No
VIA5002 One channel 1 of 2 –1.1dB No
Bridging not available NA NA NA
VIA2004 One channel 1 of 4 No No
Bridging not available NA NA NA
For explanation, see Amplifier compatibility legend (page 21).
Amplifier compatibility legend
Yes The amplifier channel can deliver the required power
to achieve the full pink noise rated output of
the loudspeaker, providing a reasonable amount of
headroom for dynamic music content.
‑1.0dB The amplifier channel can meet the RMS output of the
loudspeaker (20 Hz–20 kHz sine wave), but the peak
output is attenuated by the number of decibels shown,
limiting its ability to reproduce dynamic music content.
No The amplifier channel does not meet the loudspeaker’s
pink noise or RMS power requirements and is therefore
not recommended. However, it may still be suitable if the
application does not demand the full rated output of the
loudspeaker.
NN Not needed: bridging channels is unnecessary, as a
single amplifier channel provides sufficient power to
drive the speaker.
NA Not available: bridging channels isn't available with this
amplifier.
Note that it is far more likely that an underpowered
amplifier will damage a loudspeaker than one with excess
power. Modern limiters in speaker presets can safely
manage the amplifier’s output. However, driving a system
into distortion due to an insufficiently powered amplifier
can cause heat buildup and lead to voice coil burnout,
which is the most common form of loudspeaker damage.
If you need assistance with system design, please contact
the Martin Audio Technical Support Team.
BlacklineQ User Guide
21
