Martin Audio – Blackline Series
ENGLISH
18
S218
TYPE Dual driver vented sub bass system
FREQUENCY RESPONSE 35Hz-150Hz ±3db
RATED POWER 1000W AES, 4000W peak
SENSITIVITY 102dB
MAXIMUM SPL 130dB continuous, 136dB peak
RECOMMENDED AMPLIFIER 800-2000W (into 4 ohms)
DISPERSION —
NOMINAL IMPEDANCE 4 ohms
BASS 2 x 460mm (18'')
MID —
HIGH FREQUENCY —
CROSSOVER 150Hz active
ENCLOSURE 320 litre, multi laminate birch ply
FINISH Textured black paint
GRILLE Black perforated steel
CONNECTOR 2 x Neutrik NL4
FITTINGS 4 x 100mm castors
DIMENSIONS (W) 561mm x (H) 1066mm x (D) 780mm
(W) 22.1ins x (H) 42ins x (D) 30.7ins
WEIGHT 87kg (191.5lbs)
SHIPPING DIMENSIONS (W) 570mm x (H) 1090mm x (D) 930mm
(W) 22.4ins x (H) 42.9ins x (D) 36.6ins
SHIPPING WEIGHT 92kg (202.8lbs)
Due to our policy of continuous improvement all specifications are subject
to change without notice.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
