9 WARRANTY
Martin Audio Blackline Series products are warranted against manufacturing
defects in materials or craftsmanship over a period of 5 years from the date
of original purchase. During the warranty period Martin Audio will, at it's
discretion, either repair or replace products which prove to be defective
provided that the product is returned in its original packaging, shipping
prepaid, to an authorised Martin Audio service agent or distributor.
Martin Audio Ltd. cannot be held responsible for defects caused by
unauthorised modifications, improper use, negligence, exposure to inclement
weather conditions, act of God or accident, or any use of this product that is
not in accordance with the instructions provided by Martin Audio.
Martin Audio is not liable for consequential damages.
This warranty is exclusive and no other warranty is expressed or implied.
This warranty does not affect your statutory rights.
10 TECHNICAL SPECIFICATIONS
Martin Audio – Blackline Series
ENGLISH
12
F12
TYPE Compact, two way passive multi-angled, vented
FREQUENCY RESPONSE 65Hz-18kHz ±3db
RATED POWER 300W AES, 1200W peak
SENSITIVITY 97dB
MAXIMUM SPL 120dB continuous, 126dB peak
RECOMMENDED AMPLIFIER 400-650W (into 4 ohms)
DISPERSION 80 degs horizontal x 50 degs vertical
NOMINAL IMPEDANCE 8 ohms
BASS 300mm (12")
MID —
HIGH FREQUENCY 25mm (1'') exit compression driver
CROSSOVER 2kHz passive
ENCLOSURE 38 litre, multi laminate birch ply
FINISH Textured black paint
GRILLE Black perforated steel
CONNECTOR 2 x Neutrik NL4
FITTINGS 10 x M8 inserts. Top hat fitting
4 x M8 bracket inserts
DIMENSIONS (W) 400mm x (H) 571mm x (D) 364mm
(W) 15.8ins x (H) 22.5ins x (D) 14.3ins
WEIGHT 21kg (46lbs)
SHIPPING DIMENSIONS (W) 520mm x (H) 650mm x (D) 470mm
(W) 20.4ins x (H) 25.6ins x (D) 18.5ins
SHIPPING WEIGHT 22kg (48.5lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
