AQ15 (standard)
AQ15TX150 (100V or 70V line option)
Main features
Wide 80° x 50° dispersion
Rotatable HF horn
55Hz – 18kHz
400W AES (1600W peak)
Two-way 8 ohm passive
15” (380mm) direct radiating LF cone + 1.4” (35mm) exit horn-loaded HF compression driver
The Martin Audio AQ15 is a two-way passive loudspeaker designed to provide very high sound
pressure levels from an architecturally friendly, heavily braced, vented enclosure. It features a 15”
(380mm) long-throw, direct radiating bass driver with a 3” (75mm) voice coil and a 2.5” (63mm)
diaphragm, 1.4” (35mm) exit compression driver coupled to a true constant directivity HF horn.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
