AQ6 Technical Specifications
TYPE Ultra-compact, two-way passive, vented trapezoid
FREQUENCY RESPONSE (1) 80Hz-20kHz ± 3dB
DRIVERS 6.5” (165mm) bass driver
1” (25mm) horn loaded dome tweeter
RATED POWER (2) 100W AES, 400W peak
RECOMMENDED
AMPLIFIER
100-200W into 4 ohms
SENSITIVITY (6) 90dB
MAXIMUM SPL (7) 108dB continuous, 114dB peak
NOMINAL IMPEDANCE 8 ohms (16 ohms optional)
DISPERSION (-6dB) 90º horizontal, 90º vertical
CROSSOVER 3.5kHz passive
ENCLOSURE 9 litre, structural foamed ABS
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 12 amp push-lock
FITTINGS 4 x M6 inserts for bracket
1 x M6 insert for safety point
OPTIONS 30W 100/70V line transformer
DIMENSIONS (W) 207mm x (H) 316mm x (D) 207mm
(W) 8.2ins x (H) 12.5ins x (D) 8.2ins
WEIGHT 6kg (13.2lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
