2.3 Pole Mount

2.3.1 Install the BR-MPM1, BR-MPM2 or KT-CDR2 pole mount bracket system on the desired pole

at the appropriate height using pole strapping or hose clamps. Pole straps are not included

and are the responsibility of the customer to source for their particular application.

3. Enclosure Preparation

3.1 Install the camera manufacturer supplied ceiling mount bracket (typically twist-to-lock) onto the

black Camera Bracket inside the enclosure. The black bracket inside the enclosure is designed

to accept typical ceiling mount brackets via four M4 fasteners and four M4 nylon locking nuts.

If this hardware cannot be sourced, the camera can also be directly installed using the supplied

2 x 1/4-20 socket head cap screws from the hardware kit. Using the camera manufacturer

supplied “mount bracket” is highly recommended to minimize overall weight while the

enclosure is being lifted for mounting.

POLE MOUNT BRACKET

POLE STRAPS
