www.marshall -usa.com
6
CV630-BI/WI/ND3/ND3W
User Manual
3.1.2 Back View
NO. Item Function Descriptions
1. RS-232 input
RS-232 input port, at most 7 cameras can be connected in a serial
connection
2. RS-232 output
RS-232 output port, at most 7 cameras can be connected in a
serial connection
3. Lock hole Lock hole of safety lock
4.
IR SELECT
The remote-control ID setting is only controlled after corresponding
to the Camera Select on the remote control
5.
DC 12 V power
Port
DC power supply connecting port
6. Ethernet port
Network cable port supports routers or hubs of PoE+ (IEEE
802.3at).
7.
Audio input Support Line In/Mic In
8. OUTPUT Switch Adjust the resolution setting. The default is 1080p/59.94
9. RS-422 Port
RS-422 connecting port, at most 7 cameras can be connected in a
serial connection
10. HDMI output HDMI output (Audio output supported)
11. 3G-SDI output
3G-SDI output(Audio output supported)
<Remark>Support the audio output of 48 KHz only/resolutions up
to 1080p 59.94/50
12. USB 3.0 port
Connect to the USB port of the computer, camera image output via
video software
<Remark> Support up to H.264 2160 29.97p/MJPEG 1080 29.97p
