www.marshall-usa.com
39
CV730-ND3/ND3W
www.marshall-usa.com
40
Chapter 8: DIP Safety Instructions
This symbol indicates that this equipment may
contain dangerous voltage which could cause
electric shock. Do not remove the cover (or
back). No user-serviceable parts inside. Refer
servicing to licensed service personnel.
This symbol indicates that there are
important operating and
maintenance instructions in this
User Manual with this unit.
Always follow these safety instructions when setting up and using the product:
1. Operation
1.1 Please use the product in the recommended operating environment, away from water or source of heat
1.2 Do not place the product on a tilted or unstable trolley, stand or table.
1.3 Please clean the dust on the power plug prior to usage. Do not insert the product’s power plug into a multiplug to prevent
sparks or a re.
1.4 Do not block the slots and openings in the case of the product. They provide ventilation and prevent the product
from overheating.
1.5 Do not open or remove covers, otherwise it may expose you to dangerous voltages and other hazards.
Refer all servicing to licensed service personnel.
1.6 Unplug the product from the wall outlet and refer servicing to licensed service personnel when the following situations happen:
• If the power cords are damaged or frayed.
• If liquid is spilled into the product or the product has been exposed to rain or water.
2. Installation
2.1 For security considerations, please make sure the standard mount you use is in line with UL or CE safety approbations and
installed by technician personnel approved by agents.
3. Storage
3.1 Do not place the product where the cord can be stepped on as this may result in fraying or damage to the lead or the plug.
3.2 Unplug this product during thunderstorms or if it is not going to be used for an extended period.
3.3 Do not place this product or accessories on top of vibrating equipment or heated objects.
4. Cleaning
4.1 Disconnect all the cables prior to cleaning and wipe the surface with a dry cloth.
Do not use alcohol or volatile solvents for cleaning.
5. Batteries (for products or accessories with batteries)
5.1 When replacing batteries, please only use similar or the same type of batteries
5.2 When disposing of batteries or products, please adhere to the relevant instructions in your country or region for disposing
of batteries or products
Precautions
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
Notice :
The changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment.
IC Warning
This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-
causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada.
Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe A prescrites
dans la norme sur le material brouilleur: “Appareils Numeriques,” NMB-003 edictee par l’Industrie.
EN55032 CE Warning
Operation of this equipment in a residential environment could cause radio interference.
Warning: Operation of this equipment in a residential environment may cause radio interference
Chapter 7: TROUBLESHOOTING
This chapter describes problems you may encounter while using CV730-ND3/ND3W. If you have
questions, please refer to related chapters and follow all the suggested solutions. If the problem still
occurred, please contact your distributor or the service center.
No. Problems Solutions
1. Boot without power signal
1. Make sure you have plugged in the power cord.
2. When using a PoE connection, ensure that the power
suppl
y
supports POE++
(
IEEE802.3bt
)
routers or hubs
2.
There is no image output
from VC-A71SN
1. Check the power supply or PoE supply functions.
2. Confirm the output signals are in streaming output.
3. Confirm whether the camera resolution can be used
together with the monitor equipment
I f 4k output, confirm the monitor equipment supports 4K
output
4. Replace the cables and make sure the
y
are not fault
y
.
3. R S-232 cannot be controlled
1. Confirm the connection is correct (RS-232 In/ Out)
2. Please make sure the Baud rate setting is the same as the
control equipment
4.
Whether the Internet can be
used for operation
Please refer to Chapter 5 Network Function Description for
the Internet usage
5.
Tally lamp is not working
when applying RS232 setting
Please make sure if the Tally lamp f unction is e nabled from
the setting menu or web page.
S etting Menu: System - Tally Lamp
W eb pa
g
e: Settin
g
- Camera - Tall
y
Lamp
6.
The camera does not save
the relevant parameters
(PTZ, AWB …) after reboot
Please make sure if the Initial Position is set to Last Operated
Position from the setting menu or web page
S etting Menu: System - Initial Position
Web pa
g
e: Settin
g
- Camera - Pan Tilt Zoom
7.
Tracking Data Output is
delayed or not updated
Please confirm that the camera is not in the following status
The following function settings m ay cause d ata output to be
delayed or not updated:
- Modify output resolution
- Modify camera mode
- Modify HDMI format
- Turn on the setting menu
- Streaming Setting
- Audio Source Settin
g
8.
The NDI/ Onvif software
cannot find the machine
Either NDI or ONVIF can be used. Please ensure the settings
on [Setting] > [Video] > [NDI|HX] page is set properly
• If
• Setting
• Web
• Setting
• Web
RS-232
