Marshall
Metal plate A - machine side
Metal plate A locking screw
Metal plate A - machine side
Marshall
4.2.2.5 Precautions for installation
1. Before installation, please confirm the orientation of the machine relative to the
object to be captured
2. It is recommended that the machine should be set at more than 1.5 meter away
from the object to be captured. Please adjust for a best distance according to the
magnification of the lens
3. The machine (including metal plates) is weighed at about 2.5 kg. If it is to be
installed on the ceiling, please use the hanger that has obtained UL security
approval to prevent the machine from falling.
4. Please check whether the camera is installed securely on a regular basis
4.2.2.6 Installation steps
1. Please adjust resolution on DIP switch at first
<Remark> Please refer to Chapter 7 DIP Switch Setting for the relevant descriptions
on DIP switch
2. Fix the metal plate A on the machine base with 4 M3 silver screws
1.5 meter
Projector
Computer
CV630-NDI Manual
www.marshall-usa.com13 14
