Marshall
3D NR
1. Off
2. Low
3. Typ
4. Max
Image Mode
1. Default
2. Custom
The user may customize
his/her desired image mode
Image Mode
Load
ENTER
Adjustable when the Image
mode is set to Custom.
After selected, the
corresponding Image mode
parameters will be read and
applied to Custom
Brightness 0 ~ A ~ 15
Adjustable when the Image
mode is set to Custom
Hue 0 ~ A ~ 15
Adjustable when the Image
mode is set to Custom
Saturation 0 ~ A ~ 15
Adjustable when the Image
mode is set to Custom
Gamma 0 ~ A ~ 3
Adjustable when the Image
mode is set to Custom
Pan Tilt
Zoom
Pan/Tilt Limit On / Off
Turn on/off the angle limit
setting
Pan Right Limit 0 ~ 170 Limit the right angle
Pan Left Limit -170 ~ 0 Limit the left angle
Tilt UP Limit 0 ~ 90 Limit the upward angle
Tilt Down Limit -30 ~ 0 Limit the downward angle
Pan Flip On / Off
Activate the reverse Pan
command
Tilt Flip On / Off
Activate the reverse Tilt
command
Marshall
Preset Speed
1. 5 deg/sec
2. 25 deg/sec
3. 50 deg/sec
4. 80 deg/sec
5. 120 deg/sec
6. 160 deg/sec
7. 200 deg/sec
8. 300 deg/sec
Set the rotation speed of the
cradle head when Preset is
executed
PTZ Speed
Comp
On / Off
Set the Pan/Tilt moving
speed to vary from the zoom
position
D-Zoom Limit X1 ~ x12 Set digital zoom limit
D-Effect Mirror
1. Off
2. Mirror
3. Flip
4. Mirror + Flip
Set the mode at which the
image is turned
Auto Focus
AF Sensitivity
1. Low
2. Middle
3. High
For AF triggering speed, the
higher the speed is, the
faster AF is triggered
AF Frame
1. Center
2. Full Frame
3. Auto
AF frame setting, when
central area was set as AF
frame, focusing will be on the
center of the screen. When
Full Frame was set as AF
frame, focusing will be
calculated based on the full
screen
PTZ Assist
On / Off
Turn on the auto focus
function in Manual
Preset AF
On / Off
On : camera will do the Auto
Focus after execute Preset
Off : will not do the Auto
Focus after execute Preset
Ethernet DHCP On / Off
Enable/Disable DHCP
setting using left and right
arrow keys and press
[ENTER] to apply setting.
CV630-NDI Manual
www.marshall-usa.com27 28
