CV630-BI/WI/ND3/ND3W
User Manual
www.marshall-usa.com
Chapter 7: DIP Switch Setting
7.1 DIP Switch
7.1.1 OUTPUT Switch
To switch via the OSD/ RS-232 Command is also available based on the last executed action
ID
Resolution
Frame Rate
Remark
0
3840 x 2160p
29.97
1
25
2
1920 x 1080p
59.94
3
50
4
29.97
5
25
6
1280 x 720p
59.94
7
50
8
29.97
9
25
A
1920x1080i
59.94
B
50
C
Reserved Reserved
D
E
F
7.2 IR Select
When using the remote control, please make sure the settings of IR SELECT and the Camera
Select of the remote control are consistent
Chapter 8: Troubleshooting
This chapter describes problems you may encounter while using CV630-BI/WI/ND3/ND3W. If you
have questions, please refer to related chapters and follow all the suggested solutions. If the problem
still occurs, please contact your distributor or the service center.
No. Problems Solutions
1.
Boot without power
signal
1. Make sure you have plugged in the power cord.
2. When using a PoE connection, ensure that the power supply
supports POE+ (IEEE 802.3at) hubs
2.
There is no image
output from the camera
1. Check the power supply or PoE supply functions.
2. Confirm the output signals are in streaming output.
3. Confirm whether the camera resolution can be used together
with the monitor equipment
n If 4k output, confirm the monitor equipment supports 4K
output
4. Replace the cables and make sure they are not faulty.
3.
The Camera image is
severely delayed
Please use 1080p or 720p 60/50 fps rather than 25/30 fps
signals.
4.
RS-232 cannot be
controlled
1. Confirm the connection is correct (RS-232 In/ Out)
2. Please make sure the Baud rate setting is the same as the
control equipment
5.
No image for 3G-SDI
output resolution
3840x2160 29.97/ 25
Please confirm the screen menu/ Dip Switch setting
3G-SDI supports output resolutions up to 1080p 59.94/50
6.
Whether the Internet
can be used for
operation
Please refer to Chapter 6 Network Function Description for
the Internet usage
7.
ONVIF software cannot
locate the machine
Please be sure to use only English alphabets or numbers in
[Setting]>[Video]> [Camera](Location) of the webpage. Using
special characters and pressing the spacebar will cause the
ONVIF software unable to locate the machine.
For VC-A62N, either NDI or ONVIF can be used. Please go to the
[Setting] > [Video] > [NDI|HX] on the web page to check if it is [Off].
8.
Tally lamp is not
working when applying
RS232 setting
Please make sure if the Tally lamp function is enabled from the setting
menu or web page.
n Setting Menu: System - Tally Lamp
n Web page: Setting - Camera - Tally Lamp
9.
The camera does not
save the relevant
parameters (PTZ,
AWB …) after reboot
Please make sure if the Initial Position is set to Last MEM from the
setting menu or web page
n Setting Menu: System - Initial Position
n
Web page: Live View-Setting – Camera Setting
- Pan Tilt
Zoom - Initial Position
www.marshall-usa.com
