Je bekijkt pagina 6 van 16
5
www.marshall-usa.com
Chapter 4: Connect Camera to Network
OSD MENU
EXPOSURE
EXPOSURE MENU
AUTO / MANUAL
Exposure mode seng
SHUTTER
1/30 - 1/10000
Shuer speed seng when Manual mode is
used
DC IRIS
CV370 & CV374 Only
DC Iris is set automacally
GAIN
0 - 30dB
Adjustable when Manual mode is used
BRIGHTNESS
Auto adjustment
Brightness is set automacally
FLICK
50 / 60Hz
An icker seng when Auto mode is used
BACKLIGHT
On/O
Backlight compensaon seng when Auto
mode is used
GAMMA
0 - 15
Gamma value seng
WB MODE
ATW
Auto tracking white balance mode (wider
dynamic range)
MANUAL
Manual mode
CT
Color Temperature mode
FLUORESCENT
Fluorescent light mode
SODIUM
Sodium light mode
AUTO
Auto WB mode
INDOOR
Indoor mode
OUTDOOR
Outdoor mode
PUSH
One push trigger mode
RED
1 - 255
Adjust red gain from Manual mode
BLUE
1 - 255
Adjust blue gain from Manual mode
COLOR
TEMPERATURE
2500K - 10000K
Adjust color temperature for CT mode
MIRROR
Enable/Disable mirror
FLIP
Enable/Disable ip
DAY&NIGHT
Insert/Remove IR Cut lter
QUALITY
2DNR
On/O
Enable/Disable 2D noise reducon
3DNR
AUTO, 1 – 4, O
Adjust 3D noise reducon
SHARPNESS
0 - 15
Adjust sharpness value
CONTRAST
0 - 15
Adjust contrast value
SATURATION
0 - 15
Adjust saturaon value
BRIGHTNESS
0 - 15
Adjust brightness value
FORMAT
SIZE
720p, 1080i, 1080p
Resoluon for CV370 & CV570
720p, 1080i, 1080p, 2160p
Resoluon for CV374 & CV574
FRAME RATE
23.98, 24, 25, 29.97, 30, 50, 59.94,
60
Available frame rates:
720p: 25/29.97/30/50/59.94/60
1080i: 50/59.94/60
1080p: 23.98/24/25/29.97/30/50/59.94/60
2160p: 25/29.97/30/50/59.94/60
VI FRAME RATE
25, 30, 50, 60
CMOS refresh rate to opmize the
performance
AUDIO
AUDIO
On/O
Enable/Disable audio
SAMPLE RATE
16000, 32000, 48000
Adjust audio sampling rate
VOLUME
0 - 100
Adjust audio volume
ENCODE MODE
AAC/LPCM
Adjust audio encoding mode
BITRATE
32000, 48000, 64000, 96000, 128000
Adjust audio bitrate
ID
Not applicable
BAUDRATE Not applicable
LANGUAGE English/Spanish Choose OSD Language
DHCP On/O Enable/Disable network DHCP mode
IP Display or manually set IP address
NETMASK Display or manually set Net Mask address
GATEWAY Display or manually set Gateway address
INFO IP Address Display the current IP address
RTSP URL Display the URL for RTSP streaming
FW VERSION Display the rmware version number
ARM VERSION Display the ARM version number
RELEASE Display the rmware release date
RESET FACTORY RESET Run factory reset
USER SETTING Save the current setting as USER
USER RESET Reset the camera to the USER saved setting
SYSTEM
OSD MENU
EXPOSURE
EXPOSURE MENU
AUTO / MANUAL
Exposure mode seng
SHUTTER
1/30 - 1/10000
Shuer speed seng when Manual mode is
used
DC IRIS
CV370 & CV374 Only
DC Iris is set automacally
GAIN
0 - 30dB
Adjustable when Manual mode is used
BRIGHTNESS
Auto adjustment
Brightness is set automacally
FLICK
50 / 60Hz
An icker seng when Auto mode is used
BACKLIGHT
On/O
Backlight compensaon seng when Auto
mode is used
GAMMA
0 - 15
Gamma value seng
WB MODE
ATW
Auto tracking white balance mode (wider
dynamic range)
MANUAL
Manual mode
CT
Color Temperature mode
FLUORESCENT
Fluorescent light mode
SODIUM
Sodium light mode
AUTO
Auto WB mode
INDOOR
Indoor mode
OUTDOOR
Outdoor mode
PUSH
One push trigger mode
RED
1 - 255
Adjust red gain from Manual mode
BLUE
1 - 255
Adjust blue gain from Manual mode
COLOR
TEMPERATURE
2500K - 10000K
Adjust color temperature for CT mode
MIRROR
Enable/Disable mirror
FLIP
Enable/Disable ip
DAY&NIGHT
Insert/Remove IR Cut lter
QUALITY
2DNR
On/O
Enable/Disable 2D noise reducon
3DNR
AUTO, 1 – 4, O
Adjust 3D noise reducon
SHARPNESS
0 - 15
Adjust sharpness value
CONTRAST
0 - 15
Adjust contrast value
SATURATION
0 - 15
Adjust saturaon value
BRIGHTNESS
0 - 15
Adjust brightness value
FORMAT
SIZE
720p, 1080i, 1080p
Resoluon for CV370 & CV570
720p, 1080i, 1080p, 2160p
Resoluon for CV374 & CV574
FRAME RATE
23.98, 24, 25, 29.97, 30, 50, 59.94,
60
Available frame rates:
720p: 25/29.97/30/50/59.94/60
1080i: 50/59.94/60
1080p: 23.98/24/25/29.97/30/50/59.94/60
2160p: 25/29.97/30/50/59.94/60
VI FRAME RATE
25, 30, 50, 60
CMOS refresh rate to opmize the
performance
AUDIO
AUDIO
On/O
Enable/Disable audio
SAMPLE RATE
16000, 32000, 48000
Adjust audio sampling rate
VOLUME
0 - 100
Adjust audio volume
ENCODE MODE
AAC/LPCM
Adjust audio encoding mode
BITRATE
32000, 48000, 64000, 96000, 128000
Adjust audio bitrate
ID
Not applicable
BAUDRATE Not applicable
LANGUAGE English/Spanish Choose OSD Language
DHCP On/O Enable/Disable network DHCP mode
IP Display or manually set IP address
NETMASK Display or manually set Net Mask address
GATEWAY Display or manually set Gateway address
INFO IP Address Display the current IP address
RTSP URL Display the URL for RTSP streaming
FW VERSION Display the rmware version number
ARM VERSION Display the ARM version number
RELEASE Display the rmware release date
RESET FACTORY RESET Run factory reset
USER SETTING Save the current setting as USER
USER RESET Reset the camera to the USER saved setting
SYSTEM
CV370/CV374/CV570/CV574 camera comes with DHCP enabled by default.
If the camera is connected to a router or DHCP enabled network device, it will be assigned
with an IP address automatically.
To connect to a camera, use a device or software such as NDI Studio Monitor to access
the camera and conrm the IP address of the camera.
If the connected network does not support DHCP, the camera will take 30 seconds to
assign the default IP address 192.168.100.150.
The computer that will access the camera must be connected to the same network and
proper IP address, subnet mask, and default gateway must be assigned to the computer.
Open a web browser and enter the IP address of the camera.
http://192.168.100.150 (default IP address if DHCP is not used)
