3
Chapter 2: Package Contents
CV355-27X-IP
Chapter 3: Function Introduction
3.1: I/O functions Introduction
NO. Item Function Descriptions
1
Lens 30x HD camera lens
2
Tally indicator light Display the tally light status of the camera
3
Network port
Network port, support routers or hubs (IEEE 802.3 af) with PoE power
supply support
4
3G-SDI output The factory setting for the output resolution is 1080P/6 0
5
HDMI output HDMI output
6
RS232 output
RS232 output port, at most 7 cameras can be connected in a serial
connection
7
RS232 input
RS232 input port, at most 7 cameras can be connected in a serial
connection
8
DC 12 V power
connector
AC power supply connecting port
9
Power indicator
light
After power is on, the indicator light will display in red
10
Audio input Support Line In/Mic In
11
Audio output Support 3.5 mm audio input
12
Tripod screw holes The camera is mounted on a (specification) 1/4”, 20 UNC tripod deck
Power Cord Power Adapter
3.2 Tally Indicator Light Function Description
The Tally lamp function may be enabled through the RS232 command.
Please refer to RS-232 command set document
