17

Basic Settings

CV Meaning Value

1 Address (lower part) 0 – 63

8 Reset 8

9 Address (upper part) 0 – 7

38

Hobby color light signal 0 = off / 1-10 =

brightness

0 – 10

79

Preset Operating Mode

(See Page 18)

0 – 4

Programming an Address

Two CVs (CV1; CV9) must be set in order to program an

address in DCC. The turnout group address is set. The

individual turnout addresses are generated in the same way

as when setting the address with the dip switches.

Turnout group address = CV1 + (CV9 x 64)

Example:

CV1 = 15, CV9 = 3 ->

Turnout group address: 15 + (3 x 64) = 207

Individual turnout addresses: 207 x 4 - 3 = 825

Turnouts have the individual turnout addresses 825 to 828.

Operation with DCC

Dip switch 10 must be set at “ON“ for operation of the m84

with DCC.

The users connected to the decoder can now receive

commands and be switched at the address that has been

set. The status lights on the decoder indicate the switching

status at the outputs (green / red).

Programming on the Programming Track

If the address itself is to be changed by means of program-

ming, then the decoder must be connected to the program-

ming track and the dip switches 1 to 9 must be set at “OFF”

– the decoder can then be programmed.
