Features
1. Woofer: The woofer unit is 4" in
diameter. It includes a high-
temperature voice coil and 4"
polypropylene treated paper cone. The
woofer delivers balanced mid- and
low-frequency response.
2. Tweeter: By employing a specially
developed 1" silk cone, the tweeter
can deliver an extremely natural
response. It minimizes resonance by
adapting a unique internal damping
technology.
3. Bass Reflex Port: The hole in the rear
panel is a bass reflex port. It is
designed to discharge very low
frequency signals and enhance the
overall bass response.
4. Enclosure: Along with the other
components, the Studio Scope 4's
enclosure plays an important role. In
order to provide more stable
performance, we used a special
medium-density fiberboard (MDF) and
unique interior reinforcement designed
to absorb vibration and minimize
distortion. Additionally, our innovative
loudspeaker loudspeaker cabinet
includes carefully placed acoustic
material that makes the Studio Scope
4 sound much bigger than it is—
resulting in a smooth, natural bass
response.
5. Stereo Auxiliary Input and Headphone Output: For maximum flexibility, we have included a stereo
“Aux” input which allows you to plug in a secondary audio source (such as your portable music player) in
addition to the main RCA inputs. The volume control works on all inputs simultaneously. Additionally,
there is a stereo headphone output next to the “Aux” jack that mutes the sound coming out of the
loudspeakers and redirects it to your headphones.
6. Volume Control: Use the volume control to set the output sound pressure from the Studio Scope 4 to
proper levels as required.
7. Loudspeaker Wire Input/Output: Connect your speaker wire from the loudspeaker wire output to the
loudspeaker wire input.
8. RCA Inputs: Use RCA cables (sold separately) to connect an external sound source to these inputs.
9. Power Switch: Use this switch to power the loudspeaker on or off.
10. Power Cable Input (IEC): Insert the included power cable here.
2
5
1
4
6
1
2
4
3
7
8
9
10
3
7
