4
Features
Top Panel
Channels
Note: The channels have essentially the same
controls with some minor variations between
Channels 1–2, 3–4, 5/6, and 7/8. The four
different channel types are shown here.
1. Mic Input: Connect a microphone or line-
level device to these inputs with an XLR
cable.
2. Line Input: Connect line-level devices to
these inputs with 1/4” (6.35mm) cables.
3. Insert: Use a standard 1/4” (6.35mm) TRS
cable to connect an external processor
(such as a compressor, limiter, external EQ
unit, etc.) to this jack. The signal will be
taken after the channel’s gain control and
returned before the channel’s EQ controls.
The tip of the TRS connection is the send,
and the ring is the return.
4. Gain: Adjusts the channel audio level (pre-
fader and pre-EQ gain). Adjust this so that
the Signal LED lights up.
5. Peak LED: The LED will flash if the signal
is clipping. If this happens, decrease the
setting of the Gain knob.
6. Low Cut Filter: When this button is
depressed, that channel’s audio will be
sent through a 75 Hz low-frequency filter
with a slope of 18 dB per octave. This is
useful for reducing low-frequency noise
when using microphones.
7. Compressor: Adjusts the amount of
compression on the channel, applied by
the mixer’s built-in compressor. The LED
next to the knob will light up when the
compressor is on.
8. Hi EQ: Adjusts the high (treble) frequencies
of the channel.
9. Mid EQ: Adjusts the mid-range frequencies
of the channel.
10. Low EQ: Adjusts the low (bass) frequencies
of the channel.
1
2
3
4
7
8
9
10
11
12
13
14
15
16
5
6
1
2
3
4
8
9
10
11
12
13
14
15
16
5
6
1
2
2
4
8
9
10
11
12
13
14
15
16
5
6
2
2
4
8
9
10
11
12
13
14
15
16
5
